Insulated Female Disconnects |
| |
|
|
| |
| |
Sectional area of conductor:0.5 - 1.5 mm ² (A.W.G 22 - 16 ) Imax = 10A Material: Copper |
Item No |
NEMA TAB |
Thickness |
Dimension |
color |
B |
dΦ |
DΦ |
L |
H |
FDD 1.25 - 110(5) |
0.5 x 2.8 |
0.3 |
3.8 |
1.7 |
3.8 |
19 |
10 |
red |
FDD 1.25 - 110(8) |
0.8 x 2.8 |
0.3 |
3.8 |
1.7 |
3.8 |
19 |
FDD 1.25 - 187(5) |
0.5 x 4.75 |
0.35 |
5.6 |
1.7 |
3.8 |
19 |
FDD 1.25 - 187(8) |
0.8 x 4.75 |
0.35 |
5.6 |
1.7 |
3.8 |
19 |
FDD 1.25 - 205 |
0.8 x 5.2 |
0.35 |
6.5 |
1.7 |
3.8 |
20 |
FDD 1.25 - 250 |
0.8 x 6.35 |
0.4 |
7.4 |
1.7 |
3.8 |
21 |
|
| |
| |
Sectional area of conductor:1.5 - 2.5 mm ² (A.W.G 16 - 14 ) Imax = 15A Material: Copper |
Item No |
NEMA TAB |
Thickness |
Dimension |
color |
B |
dΦ |
DΦ |
L |
H |
FDD 2 - 110(5) |
0.5 x 2.8 |
0.3 |
3.8 |
2.3 |
4.3 |
19 |
10 |
blue |
FDD 2 - 110(8) |
0.8 x 2.8 |
0.3 |
3.8 |
2.3 |
4.3 |
19 |
FDD 2 - 187(5) |
0.5 x 4.75 |
0.35 |
5.6 |
2.3 |
4.3 |
19 |
FDD 2 - 187(8) |
0.8 x 4.75 |
0.35 |
5.6 |
2.3 |
4.3 |
19 |
FDD 2 - 205 |
0.5 x 5.2 |
0.35 |
6.5 |
2.3 |
4.3 |
20 |
FDD 2 - 250 |
0.8 x 6.35 |
0.4 |
7.4 |
2.3 |
4.3 |
21 |
FDD 2 - 315 |
0.8 x 8.0 |
0.4 |
9 |
2.3 |
4.3 |
23 |
|
| |
| |
Sectional area of conductor:4 - 6 mm ² (A.W.G 12 - 10 ) Imax = 24A Material: Copper |
Item No |
NEMA TAB |
Thickness |
Dimension |
color |
B |
dΦ |
DΦ |
L |
H |
FDD 5.5 - 250 |
0.5 x 6.35 |
0.4 |
7.4 |
3.4 |
5.7 |
25 |
13 |
yellow |
FDD 5.5 - 375 |
1.2 x 9.4 |
0.5 |
10.9 |
3.4 |
5.7 |
29.6 |
|
| |
|
| |
|
