MODEL: S543F01 |
|
|
|
|
|
|
| |
1. Description |
| |
S543F01 mainly used in industry field for the energy quality detection. For example, use this panel meter to monitor machine. When the current is unbalance, it will appear harmonic distortion data. Moreover, it is a multi-function meter, measure active power, reactive power, apparent power, etc. Insert installation style looks more beautiful. |
| |
| |
|
2. Technical Parameters |
| |
Voltage |
3*220/380V |
Current |
3*3(6)A |
Accuracy class |
1.0 |
Frequency |
50-60Hz |
Auxiliary supply |
60-400V |
Impulse constant |
1000imp/kWh, 1000imp/kvarh |
Display mode |
128*64 LCD dot matrix display |
Power consumption |
≤1W, ＜8VA |
Starting current |
0.4%Ib |
Working Temperature |
-20～70℃ |
Average humidity value of year |
≤75% |
Meter Size |
72*72*80mm |
Net Weight |
0.2237kg |
|
| |
| |
|
3. Features |
| |
The operating hours& the consuming power are shown in a alternate display but have synchronous display—to be displayed at the same time on the same screen.
The meter has the function to memorize all the data when the power off .When the machine is switched on again after the power off ,the measurement data should continue running on and show the summing up amount in numbers. ( Note:the meter can not show the data when power off )
The meter has the displaying of the voltage, current, power, MD.
The meter has reset function. People can reset the data through Modbus RTU communication |
| |
| |
|
|
|
